Key Switch Type 30

Type 30 key switches are 1:1 equivalent to ITW series 60 switches and Stelvio Micro switches Code 500 and 501. These includes :

ITW series 60 switch equivalent
Stelvio micro switch code 500 equivalent
ITW 60-1000 switch equivalent
Stelvio Code 500 501 equivalent
ITW series 60 cross reference

Features :

Soft touch positive tactile feel SPST switches.
Standard and low profile versions
Knobs/keytops in 4 sizes and various colours
Silver plated
4 Pin configuration can be used as jumper leads to facilitate PCB layout.

Low Profile Key Switch

Function : momentary tactile
Rating : 20mA, 35V DC
Operating life : 250,000 cycles min.
Contact resistance : <25 milli Ohms

Download Datasheet for detail specification & drawing

Send Us Enquiry

Standard Key Switch

Standard momentary contact key switch
Knobs/keytops sizes : 7mm dia, 8x6 rect. 10x10mm square & 12.5x12.5mm square & 10x12.5mm rest.

Download Datasheet for detail specification & drawing

Send Us Enquiry

8 x 6 mm Rect. knobs

8 x 6 mm Rect. Knob

Standard switch with 8x6mm rect. Knob
Knob colours : Black, Yellow, Green, Blue, Grey, Orange, Red.

Download Datasheet for detail specification & drawing

Send Us Enquiry

7mm dia Knobs/keytops

7mm

Standard key switch with 7mm dia. Knob.
Knob colour : Black, Yellow, Green, Blue, Grey, Orange, Red.

Download Datasheet for detail specification & drawing

Send Us Enquiry

10x10mm Sq. Knobs/keytops

10x10mm

Standard switch with 10x10mm square knob
knob colours : Black, Yellow, Green, Blue, Grey, Orange, Red.

Download Datasheet for detail specification & drawing

Send Us Enquiry

12.5x12.5mm Sq. Knobs/keytops

12.5x12.5mm

Standard key switch with 12.5x12.5mm square knob
knob colours : Black, Yellow, Green, Blue, Grey, Orange, Red.

Download Datasheet for detail specification & drawing

Send Us Enquiry

Key Switch 10 x 12.5 Knob

10x12.5mm

Standard key switch with 10x12.5mm red knob
knob colours : Black, Grey, Red.

Send Us Enquiry

Water Proof/ Washable Tactile Switch

Dust, drip and waterproof tactile switches
Sealed construction
Silver plated
Ultra sonic cleaning is possible after soldering.
Positive tactile feel.
4 pin layout can be used as jumper leads

Dust Proof Tact Switch

Rubber Stem Sealed Switches

Dust Proof Tact Switch
Same foot print as Standard 6x6mm tact switch
Available in 5.00mm or 7.00mm height.

Download Datasheet for detail specification & drawing

Send Us Enquiry

Dust Drip Proof Switches

Dust Drip Proof Tactile Switch

Specifications :
Water Depth	10cm
Time	10 hours
Rating	50mA, 12V DC
Operating Life	100,000 & 500,000 cycles

Download Datasheet for detail specification & drawing

Send Us Enquiry

Water Proof Tact Switches

Water Proof Tactile Switch

Specifications :
Water Depth	10cm
Time	240 hours
Rating	50mA, 12V DC
Operating Life	100,000 & 500,000 cycles

Download Datasheet for detail specification & drawing

Send Us Enquiry
